AVR LEROY SOMER D350 D-350 D 350 AVR 35-9-00001-40 - GENUINE

AVR LEROY SOMER D350 D-350 D 350 AVR 35-9-00001-40 - GENUINE MADE IN FRANCE

Brand = LEROY SOMER
Part Number = D350
Description = Automatic Voltage Regulator (AVR)

AVR LEROY SOMER D350 - GENUINE PRODUCT 100%

The D350 digital automatic voltage regulator (AVR) for industrial alternators provides excitation current up to 5 A with excellent reliability for permanent magnet (PMG) or AREP (auxiliary winding) excitation types.
D350 includes advanced protections such as over-excitation limitation and voltage sensing loss. It also includes speed detection capabilities, with over- and under-speed alarms. D350 also features voltage droop for genset parallel operation, and it is equipped with a Load Acceptance Module (LAM) to handle load impact events.

Key specifications
Technology = Digital
Excitation mode = SHUNT, AREP, PMG
Rated excitation current = 5 A
Regulation accuracy (+/- %) = 0.25 %
Frequency range = 10 – 100 Hz
Voltage setting range (+/- %) = 10 %
kU/F limitation = 0.5 < k< 3
Loss of sensing voltage ✓
Over-excitation limitation ✓
Short circuit current limitation ✓
Voltage droop ✓
Parallel operation between alternators ✓
Load Acceptance Module (LAM) ✓

Compatible products :
LSA 40
LSA 42.3
LSA 44.3
LSA 46.3
LSA 47.2
LSA 49.3
LSA 50.2
TAL 40
TAL 42
TAL 44
TAL 46
TAL 47
TAL 49

Generator
